Key Performance Factors

Smooth ride quality
ALUXX aluminum frameset and new SyncDrive motor combine for confident, stable handling and quick acceleration on all types of roads from hills to flats.

Route finding info
RideControl EVO full color display with on-board navigation helps riders find their way. Smartphone connectivity makes it easy to keep the battery charged.

Longer Range
EnergyPak battery gives riders the freedom to ride farther.

Range

How far can I expect to ride on a single battery charge?

The range for a single battery charge can vary greatly depending on conditions such as the combined weight of the rider and cargo; wind resistance; tire pressure and tread profile; terrain and elevation changes; road or trail surface; outdoor temperature; maintenance of the E-Bike; and the condition of the battery.

The list below gives an approximate range. Conditions are categorized as extreme, good and ideal. Extreme conditions typically occur when riding with a heavy load, strong headwinds or excessive climbs.

Extreme: 45 km
Good: 85 km
Ideal: 165 km

Specs

Motor	SyncDrive Sport, 70Nm, powered by Yamaha
Controller	RideControl Dash
Display	RideControl Dash, full color lcd screen
Battery	EnergyPak 500
Sizes	S, M, L
Colors	Space Grey
Frame	ALUXX aluminum, Overdrive 1½ - 1⅛" head tube, integrated KS18A kickstand mount
Fork	SR Suntour NEX DS 63mm travel
Shock	n/a
Handlebar	Giant Connect Riser 31.8x690mm
Grips	Giant Contact
Stem	Giant Contour TDS 816-8FOV (S/M:80mm L/XL/XXL 100mm)
Seatpost	Giant 30.9mm, 2-bolt Micro Adjustable, Forged Aluminium
Saddle	Selle Royal Vivo Ergo Moderate
Pedals	Aluminum Platform
Shifters	Shimano Altus
Front Derailleur	n/a
Rear Derailleur	Shimano Alivio, 9-speed
Brakes	Tektro HD-M275, hydraulic disc, 180mm [F], 160mm [R]
Brake Levers	Tektro HD-M275
Cassette	Shimano CS-HG200, 11-36T, 9-Speed
Chain	KMC e.9 Sport, e-bike optimized
Crankset	Forged Alloy minimal Q-factor, 42T
Bottom Bracket	n/a
Rims	Giant eX 2, Tubeless Ready, 622x21 aluminium
Hubs	Giant eTracker, [F] 100x9mm QR [R] 135mm QR
Spokes	Stainless steel
Tires	Giant Crosscut Gravel 2, 700x50c, Tubeless Ready
Lighting	Axa BlueLine 30Lux Steady E6 [F] Axa BlueLine Steady E6 [R]
Carrier	MIK rack. System bag & basket compatible
Weight	The most accurate way to determine any bike’s weight is to have your local dealer weigh it for you. Many brands strive to list the lowest possible weight, but in reality weight can vary based on size, finish, hardware and accessories. All our bikes are designed for best-in-class weight and ride quality.
